F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT
F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT
اکنون تماس بگیرید

F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT

مقدار حداقل تعداد سفارش : 10 عدد قیمت : Negociatable
جزئیات بسته بندی : جعبه کارتن زمان تحویل : 15 روز
شرایط پرداخت : L/C، T/T قابلیت ارائه : 20000 عدد در هفته
محل منبع: گوانگدونگ نام تجاری: GPON EPON ONT
گواهی: CE ROHS Anatel شماره مدل: F663NV3A

اطلاعات تکمیلی
استفاده کنید: FTTX زمان گارانتی: 1 سال
شبکه: وای فای رنگ: سفید
منبع تغذیه: DC 12V/1A پورت ها: 1GE + 3FE

توضیحات محصول

F663NV3a FTTH is a single-frequency and economical smart gateway specially built by ZTE for China Mobile. This model uses the new-generation self-developed chip, loads the intelligent operating system, and supports dynamic loading of plug-ins, and givess users with abundant home services. The stable wireless performance provides smooth Wi-Fi for the home. Its unique open application platform creates an operator-dominated and user-centered smart home application ecosystem.F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT 0F663Nv3a FTTH Modem Router 1GE 3FE 1TEL WIFI F663 External Antenna GPON ONU ONT 1





Technical items Descriptions
Brand ZTE
Model ZXHN F663NV3a
Fiber interface SC/UPC
Fiber port 1 GPON interface, 1GE+3FE+1POT+1USB+WIFI,SC single-mode,
Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength Tx 1310nm, Rx 1490nm
Voice protocol SIP, H.248
RX sensitivity <-27dBm (1490nm)
WLAN IEEE802.11b/g/n,2*2 MIMO, 2.4G WIFI,external antenna
Net weight ≤0.6Kg
Configuration method NMS, Web, or TR069
Power ≤8W
DC power Adapter input: 100-240 V AC, 50 – 60 Hz ;
Adapter output: 11 – 14 V DC, 1 A
Button Reset, power
Operation Working temperature: -0-+40℃
working humidity:5-95%(non-condensation)
Dimension 250*220*65mm(length*width*height)
L2 forwarding capability Forwarding packets of any length at wire speed
IPv4 L3 forwarding capability 2Gbit/s with any length packets in downstream direction
1Gbit/s with any length packets in upstream direction
IPv6 L3 forwarding capability 2Gbit/s with any length packets in downstream direction
1Gbit/s with any length packets in upstream direction
LAN 1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
